Main Function:
→Used for static sealing performance test of floating seal, dynamic sealing performance test, reliability test.
→Used for determine the corrosion and wear degree of the floating oil seal assembly during running and for assessment of the reliability under strengthening use condition and for study of durability performance.
Main Specifications:
→Torque capacity: 100N.m~1000N.m
→Axial load capacity: 3000N~30000N
→Forward and reverse rotation speed: 300r/min，600r/min
→Axial moving stroke: 0～100mm
→Axial moving speed: 20～100mm/min
→Temperature range: 0～150℃
Model Options:
→Model FRST 100N.m/3000N is applicable for floating seals with diameter Ø50-Ø220mm
→Model FRST 200N.m/5000N is applicable for floating seals with diameter Ø227-Ø500mm
→Special machine can be customized for floating seals with diameter Ø548mm, Ø608mm, Ø1000mm,Ø1500mm...
Customizable Functions:
→Angle offset loading test
→Off-axis offset loading test
→Wear condition amplification observation system
→Self-locking safety protection system
→Mud and sand mixture running wear test system
→Rotation speed is greater than 1000r/min
