Function:
→ The weld ability test of PVC-U doors and windows profiles. Apply pressure to the weld angle of the profiles until it is destroyed. Record the maximum load and calculate the compression bending stress of the weld angle.
→20kN angle strength testing machine is composed of host, electric control box, measurement and control system, mechanical and electrical integration design.Adopting measurement and control system and high precision load sensor for electronic measurement and digital display.Two pulley movable support devices make the profiles welding angle specimen slide by itself during the loading test.Accurate data, stable and reliable, convenient operation.
→max. Load capacity: 20kN
→measuring range of load: 1%-100%F.S
→load accuracy: ±1%
→loading speed: 50±5mm/min
→compression test space: 200-260mm
→length of support surface center of weld angle specimen: 400±2mm
→power supply: 380V±10%, 50Hz
→power: 0.75kW
→machine (L*W*H): 740×400×1500mm
→weight: approx. 150kg
