→Horizontal tensile testing machine for closure for optical fibers and cables
→2000N/5000N/10000N optical fiber splice closure tesile test
→2000N/5000N/10000N fiber optical splice box tensile test
→2000N/5000N/10000N optical cble box test
→WGL-2000N optical fibercables splice closure connector horizontal tensile testing machine (CE CUL/CSA)
→WGL-5000N optical fiber cable splice closure connector horizontal tensile testing machine (CE CUL/CSA)
→WGL-10000N optical fibercable splice closure connector horizontal tensile testing machine (CE CUL/CSA)
→Use for tensile test for optical fiber cable splice closure photoelectric composite cable installed in the form of overhead, pipelined (tunnel), directly buried.
→Used in tensile test for optical fiber cable splice closure, applicable in shallow sea open air, corridor wall build-up, indoor and outdoor, network power, cable television, cable network, etc.
→Used in tensile test for optical fiber splice closure (cable junction box, optical cable connector box and barrel), mechanical seal cable connector box, heat shrinkable seal optical cable connector box, direct optical cable connector box, divergent optical cable connector box, horizontal optical cable connector box, cap optical fiber connector box, horizontal optical fiber connector box, unattached cable connector box.
→Used in axial tensile test, load hold test, bending test, bending cyclic test, torsion test, torsion cyclic test for heat-shrinkable casing, injection welding casing, assembling casing, used for air pressure maintenance.
→Used in axial tensile test, load hold test, bending test, bending cyclic test, torsion test, torsion cyclic test for common and enhanced heat-shrinkable casing, assembling casing, used for non-pressurized maintenance.
→Used in tensile force of optical fiber connector, tensile strength test, tensile force of splitter, tensile test of optical fiber cable, axial compression load, compression strength test, bending test.
→YD/T590.1 Plastic jacket joint closure for telecommunication cable Part 1: General specificatino
→Axial tensile test of cable: apply axial tensile force between casing and cables or cables at two ends. Inflatable casing with axial force 1000N±10N. Non-inflatable casing with axial force 700N±10N, hold time for 24h.
→Cable bending test: fill dry air or nitrogen into casing with pressure 70±2kPa and fix casing and apply axial force perpendicular to cable, not more than 500N. When force reaches 500N but deflection not more than 30°, record real bending angle.
→Cable cyclic bending test: bending cable → hold for 5min→return to original position→bending in opposite direction→hold for 5min→return to original position as one cycle. After one cycle, rotate casing for 90° along axial direction of cable and repeat one cycle.
→Cable torsion test: fill dry air or nitrogen into casing with pressure 70±2kPa (as for non-pressure maintenance 40±2kPa), and fix casing and apply 50N.m axial force to make cable torsion 90°. When force reaches 50N.m, allow torsion angle less than 90° and record real bending angle.
→Cable cyclic torsion test: cable torsion→hold for 5min→return to original position→bending in opposite direction→hold for 5min→return to original position as one cycle. Make twice torsion cycles for each cable.
→Cable static load test: fill dry air or nitrogen into casing with pressure 70±2kPa (as for non-pressure maintenance 40±2kPa). Place the casing horizontally on hard thick plate. As for longitudinal seaing casing, make the longitudinal slot of casing face side and place the round loading anvilwith area 5cm2 (air pressure maintenance type) or 25cm2 (non-air pressure maintenance type) and the the edge of anvil has 0.5 mm radius arc. Apply 1000N±10N (including the weight of anvil) on anvil and hold for 5min.
→YD/T814.1-2013 Optical fiber connector box Part 1: Outdoor optical cable connector box
→YD/T2150-2010 Fiber access terminal YD/T1272 Optical fiber movable connector
→YD/T2152-2010 Reliability requirements and test method of optical fiber movable connector
→GB/T32385.1-2015 Fiber preform Part 1: General specification
→GB/T12507.1-2000 Connectors for optical fiber
→GB/T13993.1-2016 Optical fiber cables for telecommunication-Part 1: General
→GB/T7424.2-2008 Optical fiber cable generic specification-Part 2: Basic optical cable test procedures
→GB/T51167-2016 Code for acceptance of optical fiber submarine cable systems engineering
→load capacity: 2000N/5000N/10000N
→load accuracy: ≤±1.0%; ≤±0.5%
→load resolution: 1/±300000F.S
→test space: 0-2000mm
→clamping size of cable: Ф1mm-Ф13mm
→loading rate: 0.001-600mm/min (customized 9m/min & 150mm/s high speed testing system)
→displacement resolustion: 0.001mm
→HRJ-Test software
→Touch screen system
