Asphalt & Asphalt Mixtures High and Low Temperature Testing Machine
Bitumen & Bituminous Mixtures High and Low Temperature Testing Machine
1. Introduction
→Used in tensile, compression, bending tests for highway engineering asphalt, asphalt mixtures at -15℃~+60℃.
→Applicable in modified asphalt, elastomer modified asphalt, asphalt base,petroleum asphalt, liquid petroleum asphalt,emulsified asphalt, hot-mixed bituminous mixtures,cold-mixed bituminous mixtures,modified asphalt mixtures,flexible base,semi-rigid base, rigid base, asphalt pavement,etc.
→Used in T0713-2000 Uniaxial compression test for bituminous mixtures (cylinder method Ø100*100mm): deflection compressive modulus of resilience (20℃±0.5℃ ), bending stress and compressive modulus of resilience (15℃±0.5℃),compression strength.
→Used in T0714-1993 Uniaxial compression test for bituminous mixtures (prism method 40*40*80mm): crack resistance for bituminous mixtures at low temperature (-10℃±0.5℃), compression stress, compression deformation.
→Used in T0715-2011 Bending test for bituminous mixtures (15℃±0.5℃):prism beam (250*30*35mm), bending test, tensile property for asphalt mixtures at low temperature (-10℃±0.5℃), mx.break load, bending strength.
→T0716-2011 Split test for bituminous mixtures(15℃±0.5℃): cylinder (Ø100x40mm、Ø101.6x63.5mm、Ø150x40mm), creak property test for asphalt mixtures at low temperature(-10℃±0.5℃),vertical deformation,horizontal deformation 0.001mm, load-horizontal deformation curve, load-vertical deformation curve, crack tensile strength, tensile strain, pisson`s ratio.
Test Standards
→JTG E20-2011 Standard Test Methods of Bitumen and Bituminous Mixtures for Highway Engineering
→JTG D50 Specifications for Design of Highway Asphalt Pavement
→JTG D30-2015 Specifications for Design of Highway Subgrades
→JTG F40 Technical Specifications for Construction of Highway Asphalt Pavement
2. Technical Specifications
WDW-LQ50/LQ100
|
||
No.
|
Inspection items
|
Technical specifications
|
1
|
Max. load
|
50kN/100kN
|
2
|
Load grade
|
Class 0.5/ Class 1
|
3
|
measuring range of load
|
0.4%-100% / 1%-100%
|
4
|
Relative error of indicating value
|
±0.5%
|
5
|
Load resolution
|
1/±300000F.S
|
6
|
Measuring range of deformation
|
0.2%~100%F.S
|
7
|
Deformation resolution
|
0.001mm
|
8
|
Speed range of load
|
0.005%-5%FS/S
|
9
|
Speed accuracy of load
|
If speed <0.05%FS, accuracy:±1% of the set value
If speed ≥0.05%FS, accuracy: within ±0.5% of the set value
|
10
|
Speed range of deformation
|
0.005~5%FS/s
|
11
|
Speed accracy of deformation
|
If speed<0.05%FS/s, accuracy: ±1% of the set value
If speed ≥0.05%FS/s, accuracy: within ±0.5%of the set value
|
12
|
Deformation resolution
|
0.001mm
|
13
|
Displacement speed
|
0.001-600mm/min
|
14
|
Speed accuracy of displacement
|
Within ±0.2%of the set value
|
15
|
Loading mode
|
Loading by mini computer
|
16
|
Span between columns
|
610mm
|
17
|
Stroke of crosshead
|
1400mm
|
18
|
Working voltage
|
Loading machine: 220V±10% 50Hz
|
Temperature cabinet: 380V±10% 50Hz
|
||
19
|
Motor power
|
≈2.0kW+7.0kW
|
20
|
Dimension of loading frame (L*W*H)
|
1080*2100*2320mm
|
High and low temperature cabinet
|
||
21
|
Working temperature/accuracy
|
-15℃~+60℃/±0.5 ℃
|
22
|
Temperature rising and falling speed
|
RT+10℃~60℃/≈40min;RT+10℃~-15℃/≈20min
|
23
|
Dimension of working cabinet (W*H*D)
|
Approx. 450*500*400mm
|
