Application:
→Widely used in scientific research, microelectronics industry, software technology, communication technology, new electronic components, information security technology, intelligent transportation technology, new material technology, high-tech transformation of traditional industries and other modern science and technology fields.
→Adopting the digital integrated system of data acquisition and control system, with single column structure, small, portable, easy to display and demonstrate teaching.
Main Tests
→ Used in various materials performance test, such as thin metals, silk yarn, wire, fiber, elastomer, foam, textile, food, medicine, cosmetics, rubber, plastic, film, biological material, etc.
→ Used in pull off, peel, welding strength test for electronic components.
→ Used in peeling and bending strength test for printed circuit board.
→ Used in mechanical properties test for wood products, paper products and film samples.
Specifications:
→Max. Load：5N-500N
→Test speed: 0.001-500mm/min
→Stroke of cross head: 0-300mm
→Dimension of loading frame: 380×260×900mm
→N.W.: approx. 30kg
→With portable trolley case
