Introduction
→ Diaphragm coupling tensile bending and torsion three-dimensional dynamic load fatigue test system, simulate the wind power coupling diaphragm under tensile bending and torsion three-dimensional dynamic variable load, measure the durability of the coupling diaphragm working life, study and evaluate the reliability of the coupling diaphragm for long-term service. Provide accurate test data for design and production.
→ Diaphragm coupling tensile bending and torsion three-dimensional dynamic load fatigue test system, horizontal tensile force load ≥300kN, vertical bending force load ≥±10kN, accuracy 0.5%.
→ Diaphragm coupling tensile bending and torsion three-dimensional dynamic load fatigue test system, rotary swing torque force ≥±1000N.m, accuracy 0.1°, maximum swing Angle ±45°.
→ Diaphragm coupling tensile bending and torsion three-dimensional dynamic load fatigue test pump station system is integrated with strong electric control pump station, pump station start and stop, remote computer control.
→ Special water cooler for coupling diaphragm tensile bending and torsion 3D dynamic load fatigue test pump station, which is used for cooling servo pump station without additional configuration of water cooling tower pool.
→ Video monitoring system for coupling diaphragm tensile bending and torsion 3D dynamic load fatigue test, real-time recording rolling update, recording time ≥24h, video definition ≥1080P.
→ Full digital closed loop, multi-channel multi-function, easy to control HRJ-Test multi-channel three-dimensional dynamic load fatigue endurance test software control system
